Wood/Biomass Pellet Boiler | Hot Water Boiler | Heating Boiler
CWHS series biomass fired heating boiler, capacity from 35000 kcal(41KW) to 4.8 million kcal(5600KW). It is a intergrated biomass fired steam/hot water boiler. It can be used in all industries, not only produce steam, but also used for central heating, warming, provide hot water for production&living&bathing.
| Output: | steam/hot water |
| Heating Capacity: | 41kw - 5600 kw 40,000kcal - 5 Mkcal |
| Styles: | integrated |
| Fuel: | biomass pellet, wood pellet etc |
| Applied Industries: | home, villa heating&hot water, hotel, hospital, school, bath center, breeding industry heating and hot water |
Introduction
1. CWHS series biomass wood boiler is a intergrated heating boiler that produces hot water or steam for user. It not only can achieve heating, warming, but also provide hot water for production&living&bathing.
2. Capacity from 35000 kcal(41KW) to 4.8 million kcal(5600KW). Intelligence, fast heat up, low noise and no dust. Simple structure to use it.
-- High efficiency and energy saving:
Using gasification combustion method, the combustion is complete and the thermal efficiency is >90%. Built-in waste heat recovery device efficiently utilizes flue gas and reduces heat loss.
-- Environmental protection
Integrated design of dust removal and waste heat, smoke-free and dust-free, more energy-saving and environmentally friendly.
-- Wide range of uses
It integrates multiple functions of hot water production, steam production, central heating etc, has a wide range of uses for factory production, home, villas, hospitals, hotel heating and hot water supply, schools, gymnasiums, bathing centers, breeding industry heating and hot water...
-- Easy to operate
It adopts microcomputer one-button operation, automatic feeding, automatic ignition, free temperature setting, one-button start and stop and fault alarm functions.
①Integrated design, only water, electricity, pipes, etc. need to be connected on site
②A new generation of biomass pellet combustion method
③Vertical fire tube structure, thermal efficiency as high as 92%
④The secondary power device eliminates the hidden danger of backflushing of biomass boilers
⑤Can be made into container type, easy to move
⑥The heat exchanger adopts baffle return flow method to improve thermal efficiency.
⑦Water production is 18% higher than similar products in the industry
① Steam Boiler/Generator (the boiler can produce pressure steam/vapor for production process) , Hot Water Heater Boiler (output hot water or central heating for space/buildings), Thermal Oil Heater Boiler (heating oil purpose, hot oil circulation for factory), Turbine Boiler (drive turbine, to generating electricity)
② Fuel can be: Gas, Lpg, Diesel, Heavy Oil, Coal, Wood, Biomass, Charcoal, Briquette, Pellets, Waste Fabric, Husk, Fruit Shells, Forest Waste, Paper Waste etc
③ Sructure has: Fire Tube Boiler, Water Tube Boiler, Water-Fire Tube Boiler, Chain Grate Boiler, Reciprocating Grate Boiler, Step Grate Boiler, Traveling Grate Boiler
About Our Company
■ Established in 1956, as a stated owned enterprise.
■ Over 16 years export experiences, payment & shipping protection
■ CE ASME DOSH EAC GOST ISO high standard boiler certified
■ Production of various types boilers, provide pre-sale boiler proposal for customer select
■ Directly factory low price & quality protection.
■ Completed technology & after-sale service team.
■ Support Video / VR factory-inspection. Abroad installation and commissing service etc
■ Technical discussion, drawing about boiler solution for your company use
Parameter
| BoilerModel |
Rated out put (×10⁴kcal) |
Heating area ㎡ |
Working pressure |
Thermal efficiency |
Circulating water volume(T) |
Fuel consumption (kg/h) |
Boiler size (m) |
Fuel silo size (m) |
Shipping weight(kg) |
| CWHS-0.041 | 3.5 | 350 |
Atmospheric type /0.4/0.7/1.0mpa |
0.93 | 0.875 | 6.7 | 1.7*0.7*1.3 |
Integrated design of boiler and silo |
350 |
| CWHS-0.058 | 5 | 500 | 1.25 | 9.5 | 1.7*0.7*1.4 | 450 | |||
| CWHS-0.088 | 7.5 | 750 | 1.875 | 14 | 1.9*0.8*1.4 | 700 | |||
| CWHS-0.12 | 10 | 1000 | 2.5 | 19 | 2.1*0.8*1.6 | 850 | |||
| CWHS-0.175 | 15 | 1500 | 3.75 | 29 | 2.2*0.9*1.8 | 1100 | |||
| CWHS-0.24 | 20 | 2000 | 5 | 38 | 2.3*1.1*2.1 | 1300 | |||
| CWHS-0.35 | 30 | 3000 | 7.5 | 57 | 2.7*1.1*2.2 | 1800 | |||
| CWHS-0.54 | 45 | 4500 | 11.25 | 86 | 2.9*1.3*2.4 | 2400 | |||
| CWHS-0.7 | 60 | 6000 | 15 | 114 | 3.2*1.4*2.2 | 3000 | |||
| CWHS-1.05 | 90 | 9000 | 30 | 171 | 3.1*1.5*2.2 | 1.2*1.1*2.1 | 4000 | ||
| CWHS-1.4 | 120 | 12000 | 30 | 229 | 3.7*1.7*2.5 | 1.2*1.1*2.1 | 5000 | ||
| CWHS-1.75 | 150 | 15000 | 37.5 | 286 | 4.0*1.8*2.6 | 1.6*1.2*2.3 | 5800 | ||
| CWHS-2.1 | 180 | 18000 | 45 | 343 | 4.1*1.9*2.8 | 1.5*1.4*2.9 | 6800 | ||
| CWHS-2.8 | 260 | 24000 | 60 | 457 | 4.3*1.9*2.8 | 1.5*1.4*2.9 | 12000 | ||
| CWHS-4.2 | 340 | 36000 | 90 | 686 | 5.2*2.5*3.3 | 1.6*1.5*3.1 | 15000 | ||
| CWHS-5.6 | 480 | 48000 | 120 | 914 | 5.6*2.8*3.5 | 1.7*1.6*3.3 | 18000 | ||
| CWHS-7.2 | 600 | 60000 | 150 | 1143 | 6.3*3.2*3.8 | 1.9*1.7*3.6 | 20000 |
